Cooling Fan Control Board

Cooling Fan Control Board Desing
Cooling Fan Control Board Desing

Cooling Fan Control Board

APPLICATION FIELD


This solution is applicable to household cooling fan with remote control

Share:

Product Description

Extendable Solution Areas

1. After adjustment, we can add digital display on it;

2. If need we can development the high-speed DC fan drive board on it;

1. After adjustment, digital display can be added, so that users can intuitively monitor the fan operation status and environmental parameters, and carry out interactive upgrades and intelligent control with users as the center, creating "visible" intelligent environmental management.


2.High-speed DC fan driver boards can be developed to support higher speeds, more precise speed control and lower noise, and provide "high reliability and high energy efficiency" heat dissipation guarantee based on industrial needs.

Read More

Solution Technical Highlights

Low-middle-high three fan speed gear

Low-middle-high three fan speed gear

Natural Wind Mode

Natural Wind Mode

Sleep Mode

Sleep Mode

Timer function

Timer function

1. Low, medium and high wind speeds

Personalized comfort experience: The three wind speeds allow users to flexibly switch gears according to ambient temperature, space size and personal preferences to meet different usage scenarios.

Balance between energy saving and noise: Low power consumption saves electricity daily, and the noise is equivalent to a whisper, which is suitable for quiet scenes such as libraries and baby rooms; mid-range balances cooling efficiency and energy consumption, taking into account safety and coolness, without frequent adjustments, suitable for special groups such as children, the elderly and pregnant women. High-end noise is slightly higher than normal conversation, suitable for strong wind needs.



2. Natural wind mode

Health protection upgrade:

- This mode randomly adjusts the wind speed through an algorithm, so that the wind strength presents a "rise-fall-flat" change, reproducing the breeze experience in nature, avoiding the dryness and fatigue caused by continuous single wind feeling, and increasing human comfort.

- With the swing head function, a three-dimensional airflow circulation is formed to accelerate indoor air replacement, especially suitable for small apartments with poor ventilation, reducing the probability of air conditioning disease.

Intelligent linkage expansion: supports linkage with temperature and humidity sensors to enhance the amplitude of natural wind fluctuations and accelerate the dissipation of moisture from clothes and bedding. When paired with the aromatherapy module, intermittent flow can diffuse the fragrance more evenly and avoid uneven concentration.



3. Sleep mode

Sleep quality assurance: The sleep mode will automatically perform "progressive deceleration" according to different sleep stages, and the fan will slow down to a low noise level to reduce noise interference. Synchronously turn on the "night display mode", the display brightness only displays the time and gear, and turns off non-essential indicators.

Intelligent power consumption control: Automatically adjust the output power consumption when the temperature drops at night, and the power consumption saves power compared to the normal mode.



4. Timing function

Flexible and convenient use: Users can pre-set the fan running time or shutdown time to improve the convenience of use and meet the needs of different scenarios.

Energy saving and safety double insurance: Avoids the waste of electricity caused by the fan idling for a long time, while reducing the risk of failure when unattended,


Read More

Get Started with Scheme Design + PCBA

We provide one-stop service of scheme design + PCBA, integrating design and manufacturing, which can ensure that our electronic control board perfectly carries our design scheme.
